JK BMS Smart BMS CANBUS HEAT 4S 5S 6S 7S 8S 12V 24V Battery with 2A Actice Blance RS485 HEAT CAN Lifepo4 LTO LI-ION Battery BMS

€138,99 EUR

~~€180,99 EUR~~ €138,99 EUR

Sale Sold out

Taxes included.

Color B2A8S20P-Hc B2A8S20P

Quantity

☆Package
BMS{Bluetooth bulit-in}
* Temperature sensor(40cm)
* Balance Wires(75cm)
* Active Switch(15cm)
*Heating cable(Only for BMS With Heat Function)
H:BMS With Heat Function
C:BMS With CANBUS chip Bulit-in

NOTE: For instructions on heating cables,
the green 5PIN cable of the heating cable needs to be linked to the heating pad,
and the rest of the black and red cables are linked to the smart charger
(after the smart charger links the BMS,
it detects the temperature of the battery through the BMS,
which automatically monitors the charging status of the battery)
Heat Function interface
Description of heating function:
Battery temperature is below low temperature charge protection, turn off charging, turn on heating.

Cryogenic charge protection is a parameter that can be set within APP

The heating power depends on the battery voltage and the resistance value of the heating film.

Battery voltage U.

Heating resistance R.

Power equals U*U/R

Heating current I=U/R;

The maximum I (current) of the board design is 3A.

MAX heating power 200W(100W OF B2A8S20P).

☆ Pls buy the accessory from the following link.

☆ Bluetooth link for Phone-JK BMS

Download link-IOS :Search (JK BMS) in the APP STORE

Download link-Andriod :Search (JK BMS) in the Google STORE
